Mica Heating Pad 60 x 60MM 100W 230V

Mica Heating Pad 100W 230V, 60 x 60mm, 200mm leads

For custom sizes, please call.
If you want to warm up a flat area quickly and efficiently, these Mica Heating pads, 60 x 60mm, 100W, 230V are the perfect solution. It has a spiral resistance wire that is protected by a sturdy Zintec steel sheet, which allows it to operate at temperatures up to +260°C.

This product can fit into any space where a regular heating element is not suitable. You can also put it between metal surfaces on process equipment such as moulds and dies. The unit is safe and easy to install as it has an insulated terminal and earth leads. The wires are strengthened where they connect to the pad for extra durability and strain resistance. It provides physical strength and good thermal conductivity. Specially selected mica grade and thickness are used to insulate the windings, providing excellent thermal conductivity and dielectric strength. This type of heating element is chosen for the various design options available.

This mica heater is used on packaging, manufacturing and test equipment, such as platens and laboratory machines. For optimal heat transfer results, use it with a temperature controller and clamp the pad firmly to the surface.

Temperatures are ideally measured using leaf type thermocouples that fit under the surface of the heaters.

Features

• ***Custom sizes can be made***
• Size 60x60mm
• Custom terminal and cable connections
• Various hole cutouts
• Temperatures up to 260 deg C
• Any wattage or voltage
• Built-in sensor option
• Thermal limiters

Areas of Use

• Lamination Machinery’s
• Rubber Moulding Machinery’s
• Ovens
• Sealing Machines
• Space heating
• Drying Process
